C, Z & U Purline Roll Forming Machine
Purlin roll forming machine is the most popular and has an extensive use in Metal Building Systems, Huge RoofingSolutions, Construction and Renovation Projects etc. Our Purlin roll forming machine could produce C purlin, U purlin, Z purlin, machineable size range as follow: Width:100-300mm, Height: 50-100mm, Thickness:1.5-3mm. According to your section profile, size range, thickness range we could provide you different solutions of purlin roll forming machine to manufacturer a complete range of structual purlins (height and width change using automatic system by motors): If you only need to produce few sizes, we also suggest manually change sleeves, it’s more affordable.
Product Description:
Body structure: the body is welded by steel plate. After heat treatment, the stress is eliminated and the frame is firm and durable.
Products: C Steel, Z Steel.
Features:
1. Digital control, easy to operate.
2. Length forming speed can be adjusted.
3. Applicable materials: cold rolled steel coil, Galvanized coil, Stainless steel coil.
Advantage of our purlin machines:
1. The small size less than 120mm of Z purlin made by special design , very straight and not twisted. Generally, the small size of Z purlins made by other factory is not straight and will twist.
2. A 75mm solid shaft is used, and the H-shaped steel is used as the base frame, so that the machine can withstand long-term production without deformation of the machine, thereby ensuring long-term production of quality purlins ;
3. The rollers are GCR15 material and processed by CNC machine tools to ensure the accuracy of the rollers, and thus the accuracy of the final purline.
4. Our cut frames are stress-relieved to ensure that they are not deformed during the long-term production process, making c purlin smoothly.
5. Use Mitsubishi or Siemens operating system with stable performance, simple operation
6. forming speed can reach 10-15 meters per minute
7. The c z purlin with punch machine weighs about9tons
